ASTM A249 Stainless Steel Tubes for Boilers and Heat Exchangers

ASTM A249

Product

【ASTM A249 Welded Stainless Steel Tubes for Boiler, Superheater, Heat-Exchanger and Condenser】

Product Description of ASTM A249 Stainless Steel Tube

Discover our ASTM A249 Welded Stainless Steel Tubes, meticulously engineered for superior performance in boiler, superheater, heat-exchanger, and condenser applications. YES Stainless is your reliable source for high-quality welded stainless steel tubes that meet stringent ASTM A249 standards.

Product Overview of ASTM A249 Stainless Steel Tube :

International Standard	Dimension	Stainless Steel Grade
ASTM A249, A269, JIS G3463	OD: 12.7~114.3mm WT: 1.2~2.11mm	TP304, TP304L, TP316L, SUS304TB

Key Features of ASTM A249 Stainless Steel Tube

High-Quality Stainless Steel: Crafted from premium stainless steel, our ASTM A249 tubes offer exceptional corrosion resistance, ensuring durability and reliability in harsh industrial environments.

Precision Manufacturing: Our tubes are meticulously crafted to exacting dimensions and stringent ASTM A249 standards, ensuring consistent quality and reliability in every application.

Versatile Industrial Use: Ideal for a wide range of applications including boilers, superheaters, heat-exchangers, and condensers in industries such as power generation, chemical processing, and HVAC systems.

Product Specification of ASTM A249 Stainless Steel Tube

Outside Diameter		Thickness (mm)
inch	mm	1.2	1.25	1.5	1.6	1.65	2.0	2.11
1⁄2’’	12.7	●	●	●	●	●
5⁄8’’	15.9	●	●	●	●	●	●	●
3⁄4’’	19	●	●	●	●	●	●	●
7⁄8’’	22	●	●	●	●	●	●	●
1’’	25	●	●	●	●	●	●	●
-	28	●	●	●	●	●	●	●
1 1⁄4’’	32	●	●	●	●	●	●	●
-	35	●	●	●	●	●	●	●
1 1⁄2’’	38	●	●	●	●	●	●	●
2’’	51	●	●	●	●	●	●	●
-	52	●	●	●	●	●	●	●
2 1⁄2’’	63.5	●	●	●	●	●	●	●
-	70	●	●	●	●	●	●	●
3’’	76.2			●	●	●	●	●
-	85			●	●	●	●	●
3 1⁄2’’	88.9			●	●	●	●	●
4’’	101.6			●	●	●	●	●
-	104						●	●
4 1⁄2’’	114.3						●	●
